Description
The Nikon ZR is a compact, 24.5 MP full-frame cinema camera merging RED’s R3D colour science with Nikon’s Z-mount technology. It features internal 6K/60p RAW recording, EXPEED 7 processing, and 32-bit float audio. Designed for solo creators and indie filmmakers, it boasts a fanless, lightweight body (approx. 540g) with 5-axis IBIS, 4-inch, 1000-nit monitor, and advanced AI-driven autofocus.
Sensor & Imaging: 24.5MP partially stacked full-frame sensor (6K 60p, 4K 120p).
RED Integration: Native R3D NE (Nikon/RED) and N-RAW, plus ProRes RAW/422 HQ.
Audio: World’s first camera with internal 32-bit float audio, eliminating clipping.
Processor & ISO: EXPEED 7 engine with Dual Base ISO (800/6400) and 14+ stops of dynamic range.
Design & Monitoring: Compact, fanless, weather-sealed body with a 4-inch 1000-nit, 3070k-dot touchscreen.
Stabilisation & AF: 5-axis IBIS (up to 7.5 stops) and AI-based 9-subject detection autofocus.
Workflow: Frame.io Camera to Cloud integration and dual CFexpress Type B/microSD slots.
Specifications
| Lens Mount | Nikon Z |
| Lens Communication | Yes: with Autofocus Support |
| Image Sensor | 35.9 x 23.9 mm (Full-Frame) CMOS |
| Effective Sensor Resolution | 24.5 Megapixel |
| Image Stabilization | Sensor-Shift, 5-Axis |
| Built-In ND Filter | No |
| Built-In CC Filter | No |
| Internal Filter Holder | No |
| Capture Type | Stills & Video |
| Shutter Type | Electronic Rolling Shutter |
| Shutter Speed | Electronic Shutter 1/16000 to 900 Seconds |
| Shutter Angle | 5.6 to 360° |
| ISO/Gain Sensitivity | Dual Base: 800 / 6400 Native: 100 to 64,000 |
| Advertised Dynamic Range | 15 Stops |
| White Balance | Range: 2500 to 10,000K Presets: Auto, Cloudy, Color Temperature, Direct Sunlight, Flash, Fluorescent, Incandescent, Preset Manual, Shade |
| Exposure Modes | Auto, Manual |
| Focus Mode | Automatic, Continuous-Servo AF, Full-Time Servo, Manual Focus |
| Internal Recording | ProRes RAW 12-Bit 6048 x 3402 at 25/29.97/23.98 fps 4030 x 2268 at 23.98/50/25/29.97/59.94 fps REDCODE RAW 12-Bit 6048 x 3402 at 25/29.97/50/59.94/23.98 fps (780 to 3780 Mb/s) 4030 x 2268 at 23.98/50/25/29.97/59.94 fps (700 to 1710 Mb/s) 3984 x 2240 at 100/23.98/120/50/25/29.97/59.94 fps H.265 4:2:0 8/10-Bit 5376 x 3024 at 25/29.97/50/59.94/23.98 fps 3840 x 2160 at 100/23.98/120/50/25/29.97/59.94 fps 1920 x 1080 at 200/100/23.98/240/120/50/25/29.97/59.94 fps ProRes 422 HQ 4:2:2 10-Bit 5376 x 3024 at 25/29.97/23.98 fps 3840 x 2160 at 23.98/50/25/29.97/59.94 fps 1920 x 1080 at 100/120/50/59.94 fps H.264 4:2:0 8-Bit 1920 x 1080 at 25/29.97/50/59.94/23.98 fps |
| Video Output | 3840 x 2160 |
| Fast-/Slow-Motion Support | Yes |
| Gamma Curve | Nikon N-Log, REDWideGamutRGB |
| Built-In Microphone | Stereo |
| Audio Recording | ProRes, Raw: 2-Channel, 32-Bit ProRes, Raw: 2-Channel, 24-Bit |
| IP Streaming | No |
| Media/Memory Card Slot | Slot 1: CFexpress Type B Slot 2: microSD/microSDHC/microSDXC (UHS-I) |
| Internal Storage | No |
| Video I/O | 1x Micro-HDMI Output |
| Audio I/O | 1x 1/8″ / 3.5 mm TRS Stereo Mic/Line Input 1x 1/8″ / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1x USB-C Input |
| Other I/O | 1x USB-C (USB 3.2 / 3.1 Gen 2) Data Output (Shared with Power Input) |
| Wireless | Wi-Fi / Bluetooth |
| Mobile App Compatible | Yes: Android & iOS App Name: SnapBridge |
| Global Positioning (GPS, GLONASS, etc.) | No |
| Display Type | Primary Monitor: Articulating 4″ Touchscreen LCD |
| Resolution | Primary Monitor: 3,070,000 Dot |
| Battery | Nikon EN-EL15c |
| Shoe Mount | 1x Intelligent Hot Shoe |
| Tripod Mount | 1x 1/4″-20 Female (Bottom) |
| Accessory Mounting Thread | No |
| Dimensions (W x H x D) | 5.2 x 3.2 x 1.9″ / 133 x 80.5 x 48.7 mm |
| Weight | 1.19 lb / 540 g (Body Only) | Nikon NIKKOR Z 24-200mm f/4-6.3 VR Lens Specs |
|---|---|
| Focal Length | 24 to 200mm |
| Aperture | Maximum: f/4 to 6.3 Minimum: f/22 to 36 |
| Lens Mount | Nikon Z |
| Lens Format Coverage | Full-Frame |
| Angle of View | 84° to 12° 20′ |
| Minimum Focus Distance | 1.64′ / 50 cm |
| Magnification | 1:3.57 Macro Reproduction Ratio 0.28x Magnification |
| Optical Design | 19 Elements in 15 Groups |
| Aperture/Iris Blades | 7, Rounded |
| Focus Type | Autofocus |
| Image Stabilization | Yes |
| Filter Size | 67 mm (Front) |
| Dimensions | ø: 3.01 x L: 4.49″ / ø: 76.5 x L: 114 mm |
| Weight | 1.25 lb / 570 g |
Package includes
1 x Nikon ZR 6K Cinema Camera Body
1 x Nikon EN-EL15c Lithium-Ion Battery (2280mAh)
1 x Nikon UC-E25 USB Cable
1 x Nikon BS-D1 Digital Accessory Shoe Cover
1 x Nikon BF-N1 Body Cap
1 x Nikon AN-DC26 Camera Strap
1 x Nikon NIKKOR Z 24-200mm f/4-6.3 VR Lens
1 x Nikon LC-67B 67mm Snap-On Front Lens Cap
1 x Nikon LF-N1 Rear Lens Cap
1 x HB-93 Lens Hood
1 x Nikon CL-C1 Lens Case
