Description
The OM-D E-M10 Mark IV combines Olympus’s flagship features and technologies with the compact and highly portable E-M10 design. Incorporating the 20.3MP Micro Four Thirds sensor and TruePic VIII image processor, the E-M10 Mark IV is characterized by its UHD 4K video recording capabilities, fast 8.7 fps continuous shooting rate, and wide ISO 200-25600 sensitivity range.
Specifications
| Lens Mount | Micro Four Thirds |
| Sensor Resolution | Actual: 21.8 Megapixel Effective: 20.3 Megapixel (5184 x 3888) |
| Sensor Type | 17.4 x 13 mm (Four Thirds) MOS |
| Crop Factor | 2x |
| Image Stabilization | Sensor-Shift, 5-Axis |
| Built-In ND Filter | None |
| Capture Type | Stills & Video |
| Shutter Type | Mechanical Focal Plane Shutter, Electronic Shutter |
| Shutter Speed | Mechanical Shutter 1/4000 to 60 Seconds Up to 3 Hour in Bulb Mode Electronic Front Curtain Shutter 1/320 to 60 Seconds Electronic Shutter 1/16000 to 60 Seconds |
| Bulb/Time Mode | Bulb Mode, Time Mode |
| ISO Sensitivity | 200 to 25,600 in Auto Mode (Extended: 100 to 25,600) |
| Metering Method | Center-Weighted Average, Multi-Zone, Spot |
| Exposure Modes | Aperture Priority, Auto, Manual, Program, Shutter Priority |
| Exposure Compensation | -5 to +5 EV (1/3, 1/2, 1 EV Steps) |
| Metering Range | -2 to 20 EV |
| White Balance | Presets: Auto, Color Temperature |
| Continuous Shooting | Mechanical Shutter Up to 8.7 fps at 20.3 MP for Unlimited Frames (Raw) / Unlimited Frames (JPEG) Mechanical Shutter Up to 5 fps at 20.3 MP for Unlimited Frames (Raw) / Unlimited Frames (JPEG) Electronic Shutter Up to 15 fps at 20.3 MP for up to 42 Frames (Raw) / 49 Frames (JPEG) Electronic Shutter Up to 6.3 fps at 20.3 MP for up to 945 Frames (Raw) / Unlimited Frames (JPEG) |
| Interval Recording | Yes |
| Self-Timer | 2/12-Second Delay |
| Image Sizes | 4:3 Raw 5184 x 3888 4608 x 3456 4:3 JPEG 5184 x 3888 3200 x 2400 1280 x 960 |
| Aspect Ratio | 4:3 |
| Image File Format | JPEG, Raw |
| Bit Depth | 12-Bit |
| Internal Recording Modes | H.264/MOV UHD 4K (3840 x 2160) at 23.98/25/29.97 fps [102 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94/119.88 fps [18 to 52 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps [10 to 26 Mb/s] MOV 1280 x 720 at 119.88 fps |
| External Recording Modes | HDMI UHD 4K (3840 x 2160) up to 29.97 fps |
| Recording Limit | Up to 30 Minutes |
| Broadcast Output | NTSC/PAL |
| IP Streaming | None |
| Built-In Microphone Type | Stereo |
| Audio Recording | 2-Channel LPCM Audio |
| Media/Memory Card Slot | Single Slot: SD/SDHC/SDXC (UHS-II) |
| Video I/O | 1 x Micro-HDMI Output |
| Audio I/O | None |
| Power I/O | 1 x Micro-USB Input/Output |
| Other I/O | 1 x Micro-USB (USB 2.0) Input/Output (Shared with Power Input) |
| Wireless | Bluetooth, Wi-Fi |
| Global Positioning (GPS, GLONASS, etc.) | None |
| Monitor Size | 3.0″ |
| Resolution | 1,040,000 Dot |
| Display Type | 180° Tilting Touchscreen LCD |
| Viewfinder Type | Built-In Electronic (OLED) |
| Resolution | 2,360,000 Dot |
| Eye Point | 19.2 mm |
| Coverage | 100% |
| Magnification | Approx. 0.67x |
| Diopter Adjustment | -4 to +2 |
| Focus Type | Auto and Manual Focus |
| Focus Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
| Autofocus Points | Contrast Detection: 121 |
| Built-In Flash | Yes |
| Flash Modes | Fill Flash, Off, Red-Eye Reduction, Second-Curtain Sync, Slow Sync, Slow Sync/Red-Eye Reduction |
| Guide Number | 16.73′ / 5.1 m at ISO 100 |
| Maximum Sync Speed | 1/250 Second |
| Flash Compensation | -3 to +3 EV (1/3, 1/2, 1 EV Steps) |
| Dedicated Flash System | TTL |
| External Flash Connection | Hot Shoe |
| Operating Temperature | 14 to 104°F / -10 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 30 to 90% |
| Storage Humidity | 10 to 90% |
| Battery Type | 1 x BLS-50 Rechargeable Lithium-Ion, 7.2 VDC, 1175 mAh (Approx. 360 Shots) |
| Tripod Mounting Thread | 1 x 1/4″-20 Female (Bottom) |
| Accessory Mount | 1 x Hot Shoe Mount |
| Dimensions | 4.79 x 3.32 x 1.93″ / 121.7 x 84.4 x 49 mm |
| Weight | 11.82 oz / 335 g (Body Only) 13.5 oz / 383 g (With Battery, Recording Media) |
| Olympus M.Zuiko Digital ED 14-42mm f/3.5-5.6 EZ Lens Specs | |
|---|---|
| Focal Length | 14 to 42mm (35mm Equivalent Focal Length: 28 to 84mm) |
| Maximum Aperture | f/3.5 to 5.6 |
| Minimum Aperture | f/22 |
| Lens Mount | Micro Four Thirds |
| Lens Format Coverage | Micro Four Thirds |
| Angle of View | 29° to 75° |
| Minimum Focus Distance | 7.87″ / 20 cm |
| Maximum Magnification | 0.23x |
| Optical Design | 8 Elements in 7 Groups |
| Diaphragm Blades | 5, Rounded |
| Focus Type | Autofocus |
| Image Stabilization | No |
| Filter Size | 37 mm (Front) |
| Dimensions | 2.4 x 0.9″ / 61 x 22.9 mm |
| Length at Maximum Extension | 1.9″ / 48.2 mm |
| Weight | 3.2 oz / 91 g |
| OM SYSTEM M.Zuiko Digital ED 40-150mm f/4-5.6 R Lens Specs | |
| Focal Length | 40 to 150mm (35mm Equivalent: 80 to 300mm) |
| Aperture | Maximum: f/4 to 5.6 Minimum: f/22 |
| Lens Mount | Micro Four Thirds |
| Lens Format Coverage | Micro Four Thirds |
| Angle of View | 30° to 8.2° |
| Minimum Focus Distance | 2.95′ / 90 cm |
| Magnification | 1:6.25 Macro Reproduction Ratio 0.16x Magnification |
| Optical Design | 13 Elements in 10 Groups |
| Aperture/Iris Blades | 7, Rounded |
| Focus Type | Autofocus |
| Image Stabilization | No |
| Filter Size | 58 mm (Front) |
| Dimensions | ø: 2.5 x L: 3.27″ / ø: 63.5 x L: 83 mm |
| Weight | 6.7 oz / 190 g |
Package Includes:
- 1 x Olympus OM-D E-M10 Mark IV Mirrorless Camera (Silver)
1 x Olympus BLS-50 Lithium-Ion Battery (7.2V, 1175mAh)
1 x Olympus F-5AC Adapter
1 x USB Cable
1 x Shoulder Strap
1 x Olympus M.Zuiko Digital ED 14-42mm f/3.5-5.6 EZ Lens (Silver)
1 x Olympus LC-37B Lens Cap for Olympus 45mm f/1.8 & 14-42mm f/4-5.6 II Lenses
1 x Olympus LR-2 Rear Lens Cap
1 x Olympus BLS-50 Lithium-Ion Battery (7.2V, 1175mAh)
1 x Olympus F-5AC Adapter
1 x USB Cable
1 x Shoulder Strap
1 x OM SYSTEM M.Zuiko Digital ED 40-150mm f/4-5.6 R Lens (Silver)
1 x Front Lens Cap
1 x Rear Lens Cap
