Description
Offering a fantastically compact and affordable all-in-one audio recording solution for filmmakers, musicians, podcasters, and content creators, the M4 MicTrak from Zoom delivers four tracks of crystal clear, clip-free audio thanks to its quality, stereo X/Y mic capsule with cardioid pickup pattern, two combo XLR-1/4″ TRS inputs with up to +48V phantom power, and sampling rates up to 192 kHz / 32-bit floating point. The M4 supports four modes of time code input via an auxiliary 3.5mm stereo jack, with precision down to ±0.2 ppm, a vital utility for any documentary filmmaker or content creator that needs to match audio to video with high accuracy.
Specifications
| Form Factor | Handheld Recorder |
| Primary Use Applications | Audio-for-Video, Dictation & Transcription, Podcasting |
| Number of Tracks | 4 |
| Number of Input Channels | 4 |
| Maximum Sampling Rate | 44.1 kHz / 32-Bit (PCM) 48 kHz / 32-Bit (PCM) 96 kHz / 32-Bit (PCM) 192 kHz / 32-Bit (PCM) |
| Microphone | Built-In Cardioid Stereo Pair, X/Y Configuration |
| Number of Microphone Inputs | 4 |
| Built-In Speaker | Yes, 500 mW Mono |
| Display | 1.54″ / 3.91 cm Color LCD (Backlit) |
| Memory Card Support | microSDHC (4 GB to 32 GB) microSDXC (64 GB to 1 TB) |
| Internal Storage | No |
| Special Features | Pre-Record Buffer, Remote Control Capable (Remote Available Separately) |
| Audio File Formats | Recording: BWF, iXML, WAV |
| Sample Rates | WAV: 44.1 / 47.952 / 48 / 48.048 / 96 / 192 kHz (Record) |
| Bit Depth | 32-Bit (Recording) |
| Bit Rates | 24 to 32 kb/s |
| Signal Processing & FX | No |
| Timecode Support | Yes |
| Frame Rates Supported | 23.976 / 24 / 25 / 29.97 / 29.97 DF / 30 / 30 DF |
| Clock Accuracy | ±0.2 ppm |
| Included Software | No |
| Analog I/O | 2x Combo XLR-1/4″ TRS Female Line/Mic Input 1x 1/8″ / 3.5 mm TRS Female Mic Input 1x 1/8″ / 3.5 mm TRS Female Line Output 1x 1/8″ / 3.5 mm TRS Female Headphone Output |
| Digital I/O | No |
| Phantom Power | +24 / 48 V |
| Phantom Power Current | 10 mA per Channel (Max) |
| Plug-In Power | No |
| System Connection | 1x USB-C (2.0) |
| Audio Interface Capability | Multi-Track |
| Wireless | No |
| Mobile App Compatible | No |
| Max Input Level | Mic Inputs: +4 dBu Line Inputs: +24 dBu |
| Max Output Level | Line Outputs: +1 dBu |
| Headphone Output Power | 20 mW per Channel into 32 Ohms |
| Impedance | Mic/Line Inputs: 3 Kilohms (Line Level, Mic Level) 1/8″ / 3.5 mm Inputs: 2 Kilohms (Mic Level) Timecode Input: 4.6 Kilohms Timecode Output: <50 Ohms |
| Equivalent Input Noise (EIN) | -127 dBu |
| Microphone Sensitivity | -42 dB (X/Y) |
| Microphone Max SPL | 135 dB SPL (X/Y) |
| Power Options | Battery, USB Bus Power |
| Battery Type | 4x AA (Not Included) |
| Approximate Battery Life | WAV 48 kHz/32-Bit: 18 Hours (AA Alkaline) |
| AC/DC Power Adapter | 5 VDC at 1 A (Not Included) |
| Mounting Options | 3/8″-16 Female (Bottom) |
| Package Weight | 0.955 lb |
| Box Dimensions | 9 x 4.7 x 2.6″ |
Package includes
- 1 x Zoom M4 MicTrak Stereo Microphone and Recorder
1 x Windscreen
