Description
The Canon EOS R5 Body features a newly developed 45MP CMOS sensor, which offers 8K raw video recording, 12 fps continuous shooting with a mechanical shutter, and is the first EOS camera to feature 5-axis sensor-shift image stabilization.
Specifications
| Lens Mount | Canon RF |
| Sensor Resolution | Actual: 47.1 Megapixel Effective: 45 Megapixel (8192 x 5464) |
| Sensor Type | 36 x 24 mm (Full-Frame) CMOS |
| Image Stabilization | Sensor-Shift, 5-Axis |
| Built-In ND Filter | None |
| Capture Type | Stills & Video |
| Shutter Type | Electronic Shutter, Mechanical Focal Plane Shutter |
| Shutter Speed | Mechanical Shutter 1/8000 to 30 Seconds Electronic Front Curtain Shutter 1/8000 to 30 Seconds Electronic Shutter 1/8000 to 0.5 Seconds |
| ISO Sensitivity | Photo 100 to 51,200 in Manual Mode (Extended: 50 to 102,400) Photo 100 to 51,200 in Auto Mode Video 100 to 25,600 (Extended: 51,200) |
| Metering Method | Center-Weighted Average, Evaluative, Partial, Spot |
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
| Exposure Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Metering Range | -3 to 20 EV |
| White Balance | 2000 to 10,000K Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
| Continuous Shooting | Mechanical Shutter Up to 12 fps at 45 MP for up to 180 Frames (Raw) / 350 Frames (JPEG) Electronic Shutter Up to 20 fps at 45 MP for up to 83 Frames (Raw) / 170 Frames (JPEG) |
| Interval Recording | Yes |
| Self-Timer | 2/10-Second Delay |
| Image Sizes | 3:2 JPEG / Raw 8192 x 5464 5808 x 3872 4176 x 2784 2976 x 1984 2400 x 1600 |
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
| Image File Format | JPEG, Raw |
| Bit Depth | 14-Bit |
| Raw Recording | Raw 12-Bit 8192 x 4320 at 23.98/24.00/25/29.97 fps [2600 Mb/s] |
| Recording Modes | H.265 4:2:2 10-Bit DCI 8K (8192 x 4320) at 23.98p/24.00p/25p/29.97p [680 to 1300 Mb/s] UHD 8K (7680 x 4320) at 23.98p/25p/29.97p [680 to 1300 Mb/s] DCI 4K (4096 x 2160) at 23.98p/24.00p/25p/29.97p/59.94p/100p/119.88p [170 to 1880 Mb/s] UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p/100p/119.88p [170 to 1880 Mb/s] Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p [28 to 230 Mb/s] H.264 4:2:0 8-Bit DCI 8K (8192 x 4320) at 23.98p/24.00p/25p/29.97p [470 to 1300 Mb/s] UHD 8K (7680 x 4320) at 23.98p/25p/29.97p [470 to 1300 Mb/s] DCI 4K (4096 x 2160) at 23.98p/24.00p/25p/29.97p/50p/59.94p/100p/119.88p [120 to 1880 Mb/s] UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p/100p/119.88p [120 to 1880 Mb/s] Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p [12 to 180 Mb/s] |
| Sensor Crop Modes | Super35 / APS-C 4K |
| Gamma Curve | Canon Log, Canon Log 3 |
| Recording Limit | Up to 29 Minutes, 59 Seconds |
| Video System | NTSC/PAL |
| Built-In Microphone Type | Stereo |
| Audio Recording | AAC Audio LPCM Audio |
| External Recording Modes | 4:2:2 10-Bit via HDMI DCI 4K (4096 x 2160) up to 59.94p UHD 4K (3840 x 2160) up to 59.94p |
| IP Streaming | Yes |
| Media/Memory Card Slot | Slot 1: CFexpress Type B Slot 2: SD/SDHC/SDXC (UHS-II) |
| Video I/O | 1 x Micro-HDMI Output |
| Audio I/O | 1 x 1/8″ / 3.5 mm TRS Stereo Microphone Input on Camera Body 1 x 1/8″ / 3.5 mm TRS Stereo Headphone Output on Camera Body |
| Other I/O | 1 x USB Type-C (USB 3.2 / 3.1 Gen 2) Input/Output (Shared with Power Input) 1 x Canon N3 Control Input |
| Power I/O | 1 x USB Type-C (5 VDC at 1.5 A) Input |
| Wireless | 5 GHz Wi-Fi 5 (802.11ac), Bluetooth Control |
| Global Positioning (GPS, GLONASS, etc.) | None |
| Monitor Size | 3.2″ |
| Resolution | 2,100,000 Dot |
| Display Type | Free-Angle Tilting Touchscreen LCD |
| Secondary Display | Top: Status Display |
| Viewfinder Type | Built-In Electronic (OLED) |
| Size | 0.5″ |
| Resolution | 5,760,000 Dot |
| Eye Point | 23 mm |
| Coverage | 100% |
| Magnification | Approx. 0.76x |
| Diopter Adjustment | -4 to +2 |
| Focus Type | Auto and Manual Focus |
| Focus Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
| Autofocus Points | Phase Detection: 1053 |
| Autofocus Sensitivity | -6 to +20 EV |
| Built-In Flash | No |
| Maximum Sync Speed | 1/250 Second |
| Flash Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Dedicated Flash System | eTTL |
| External Flash Connection | Hot Shoe |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 85% |
| Battery Type | 1 x LP-E6NH Rechargeable Lithium-Ion |
| Tripod Mounting Thread | 1 x 1/4″-20 Female (Bottom) |
| Accessory Mount | 1 x Hot Shoe Mount |
| Material of Construction | Magnesium Alloy |
| Dimensions | 5.43 x 3.84 x 3.46″ / 138 x 97.5 x 88 mm |
| Weight | 1.62 lb / 738 g (With Battery, Recording Media) |
Package includes
-
1 x Canon EOS R5 Body With R Mount Adapter
1 x Canon LP-E6NH Lithium-Ion Battery (7.2V, 2130mAh)
1 x Canon LC-E6 Charger for LP-E6 Battery Pack
1 x Canon R-F-5 Camera Cover
1 x Battery Pack Cover
1 x Strap ER-EOSR5
1 x Canon IFC-100U Interface Cable (39.4″)
1 x IFC Cable IFC-100U Protector
